Four Axis Cnc Glass / Stone Engraving Machine High Steel Mechanical Heavier Bed

    Buy cheap Four Axis Cnc Glass / Stone Engraving Machine High Steel Mechanical Heavier Bed from wholesalers

    Buy cheap Four Axis Cnc Glass / Stone Engraving Machine High Steel Mechanical Heavier Bed from wholesalers
    • Buy cheap Four Axis Cnc Glass / Stone Engraving Machine High Steel Mechanical Heavier Bed from wholesalers
    • Buy cheap Four Axis Cnc Glass / Stone Engraving Machine High Steel Mechanical Heavier Bed from wholesalers

    Four Axis Cnc Glass / Stone Engraving Machine High Steel Mechanical Heavier Bed

    Ask Lasest Price
    Brand Name : BLUE ELEPHANT
    Model Number : ELE1530
    Certification : CE ,ISO9001 , SGS,CIQ
    Price : 15999-25999$
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 200sets per Month
    Delivery Time : 15-20 working days
    • Product Details
    • Company Profile

    Four Axis Cnc Glass / Stone Engraving Machine High Steel Mechanical Heavier Bed

    High Steel Mechanical heavier bed , 1530 for sale wood marble glass stone engraving cnc router


    CNC Router Features:


    1 , High Steel Mechanical heavier bed, vibration aging treatment

    ------------- to ensure stable and durable, work well for years without deformation;


    2 , With Taiwan TBI precision automatic anti-backlash ball screw & helical rack gear transmission

    ------------- ensure the high speed and processing size accurate precision;


    3 , high-speed and big power stepper motor driver

    ------------- ensure that cnc router can work 28 to 33 meters/minute


    Technical Parameters:


    NumberDescriptionParameter
    1X,Y,Z Working Area1500x3000x300mm
    2X,Y,Z Traveling Positioning Accuracy±0.03/300mm
    3X,Y,Z Repositioning Accuracy±0.03mm
    4Table SurfaceVacuum&T-slot Table
    5FrameWelded Structure
    6X, Y StructureRack and Pinion Drive, Hiwin Rail Linear Bearings
    7Z StructureHiwin Rail Linear Bearings and Ball Screw
    8Max. Power Consumption(Without Spindle) 2.5kw~3Kw
    9Max. Rapid Travel Rate33000mm/min
    10Max. Working Speed25000mm/min
    11Spindle Power3KW air cooling spindle
    12Spindle Speed0-24000RPM
    13Drive MotorsStepper System
    14Working VoltageAC380V/50/60Hz,3PH (Option: 220V)
    15Command LanguageG Code
    16Operating SystemDSP/NCstudio/Syntec
    17Computer InterfaceUSB
    18Flash Memory128M(U Disk)
    19ColletER25
    20X,Y Resolution<0.01mm
    21Software CompatibilityType3/UcancameV9 Software, (Option: Artcam Software)
    22Running Environment Temperature0 - 45 Centigrade
    23Relative Humidity30% - 75%

    Application and samples:


    1 . WoodFurniture Industry: Wave Plate, fine pattern, antique furniture, wooden door, screen, craft sash, composite gates, cupboard doors, interior doors, sofa legs, headboards and so on.

    2 . Advertising industry: advertising identification, sigh making, Acrylic engraving and cutting, crystal word making, blaster molding, and other advertising materials derivatives making.

    3 . die industry:A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand, plastic sheeting, PVC pipe, wooden planks and other non-metallic mold.

    4 . relief sculpture and 3D engraving


    Warranty and Technical Support


    18 months for the whole machine

    24 Hours technical support by email or calling

    user friendly English manual and Video CD for machine operation and maintain
