1.5kw water cooling spindle , 1212 Wood, MDF, Plastic , PVC CNC
router Engraving Cutting cnc machine price list
Application:
1 . WoodFurniture Industry: Wave Plate, fine pattern, antique
furniture, wooden door, screen, craft sash, composite gates,
cupboard doors,interior doors, sofa legs, headboards and so on.
2 . Advertising industry: advertising identification, sigh making,
Acrylic engraving and cutting, crystal word making, blaster
molding, and other advertising materials derivatives making.
3 . Die industry: A sculpture of copper, aluminum, iron and other
metal molds, as well as artificial marble, sand, plastic sheeting,
PVC pipe, wooden planks and other non-metallic mold.
4 . Relief sculpture and 3D engraving
5 . Cylindrical object
Features:
1 , Advertising CNC router with rotary device which can work on
cylinder
2 , Rotary device with max. 120mm diameter and 1200mm length
3 , Mist cooling sprayer for working on metal
4 , 1.5kw water cooling spindle with 24000RPM
5 , DSP controller with USB interface
Parameter
| Working area | 1200*1200mm( 1200*1800 for option) |
| Spindle | 1.5/2.2/3KW water cooling spindle(air cooling spindle for option) |
| Spindle rotating speed | 24000RPM |
| Motor | Stepper( servo for option) |
| Inverter | FULING brand ( Taiwan DELTA for option) |
| Control system | DSP /Mach3/Ncstudio |
| X,Y,Z | Ball screw imported from Taiwan |
| Table surface | Vacuum working table |
| Frame | Cast Iron |
| Positioning accuracy | ±0.02/300mm |
| Repositioning accuracy | ±0.01mm |
| Max. engraving speed | 6,000mm/min |
| Max. motion speed | 8,000mm/min |
| Tools diameter | ER11/ER20 |
| Dictate format | G code,U00,mmg,plt/HPGL/NC |
| Compatible software | Type3,Ucancam,ArtCAM |
| Support software | Windows98/2000/XP |
| Working supply | AC220V, 1 phase,50/60HZ(110V for option) |
| Guarantee | One year |
| option | vacuum table, dust collector, rotary device, mist sprayer, flume |
| Application | Furniture, wood craft, decorative products, signs, building models,
metal, embossed pictures. |
| Technical support | 24 Hours technical support by email or calling User friendly English manual and Video CD for machine operation and
maintain |
After-sale service:
1 , Within 7 days since your local customs clearance: if the cnc
router’s any parts has any problems, we will change it free.
2 , Exceed 7 days since your local customs clearance but within
warranty period: if the cnc router parts have any problems, we can
change the old machine parts to new ones free, but you should pay
all the shipping cost.
3 , Exceed warranty period: if the cnc router parts have any
problems, we can offer new machine parts with cost price and you
also should pay all the shipping cost.
4 , We offer 24 hours technical support by call, email
5 , Our technician can give you remote guide online(Skype or MSN)
if you have any question
6 , We can record videos of operating the laser machine
7 , Free training course in our factory
8 . Machine will be adjusted before it is delivered , operation
disk/CD was included.
Company Information
Jinan Blue Elephant CNC Equipment Co., Ltd is located in Jinan City , Shandong Province .
We have always been developing to the research and manufacturer of
CNC router machine and laser
cutting engraving machine .
We have our R & D department , Quality control department , and
after sale &service department .
Our products are widely used in Woodworking ,Advertising , Model
,Electric , CAD/CAM Industry model ,
Clothing , Package Printing , Marking , Laser sealing and so on .
We had got CE and FDA certification always offer best quality
machine .
Our Philosophy : To Be First Brand -- CNC Manufacturer & wholesaler
Platform !
Just looking forward to service every customer, like you .
