ELE 1533 dsp control system cnc routerr / wood cnc router with
rotary attachment / wood carving cnc router
Features of linear atc cnc router
1 . 9kw original imported Italy HSD ATC spindle.
World best brand,has after-sale service all over the world.Match
with 11kw Taiwan DELTA inverter.
2 . Germany Siemens 808D control system.
With advanced control panel,even there's sudden electricity
power-off,you needn't reset from beginning.
3 .1KW Germany Siemens servo motors and drivers.
Match with Siemens control system,which provide the strongest power
for machine .
4 . Taiwan HIWIN linear rail 25#.
Smooth and precise transmission,low noise and lifetime is 10 times
longer than common rail way.
5 . Vacuum & T-slot table.
Can both absorb big material by vacuum power & fix small material
by clamp.There is MDF board on it for protection.
Applications of linear atc cnc router
Woodworking industry wave plate processing, wood cabinet, cupboard
door, fine pattern’s engraving, carving of the antique furniture,
craft wood door, paint-free door, byobu, craft casement,etc.
Also can for advertising signs, acrylic brands, 3D characters,
garden or wall decoration, logo, forming system module, billboard,
plate, LED/neon channel, literal-hole cut, blister Lightbox mold…
Parameters of linear atc cnc router
| 1 | Model | DX 1533 ATC |
| 2 | X,Y Working Area | 1500*3300mm |
| 3 | X,Y,Z Traveling Positioning Accuracy | ±0.03/300mm |
| 4 | X,Y,Z Repositioning Accuracy | ±0.03mm |
| 5 | Table Surface | T-slot &Vacuum working table (Option: T-slot Table) |
| 6 | Frame | Thicken steel Square Tube Heavy structure 8mm thicken steel gantry with T type |
| 7 | X, Y Structure | Gear and rack transmission, Taiwan HIWIN Linear Rail |
| 8 | Z Structure | Taiwan TBI Ball Screw, Taiwan HIWIN Linear Rail |
| 9 | Max. Power Consumption | (Without Spindle) 4.5Kw |
| 10 | Max. Rapid Travel Rate | 60000mm/min |
| 11 | Max. Working Speed | 25000mm/min |
| 12 | Spindle Power | 9KW HSD ATC spindle from Italy |
| 13 | Spindle Speed | 0-24000RPM |
| 14 | Drive Motors | Germany SIEMENS Servo Motor Driver (optional:Japan YASKAWA Servo Motor Driver) |
| 15 | Working Voltage | AC380V/50/60Hz,3PH (Option: 220V) |
| 16 | Command Language | G Code |
| 17 | Operating System | Germany SIEMENS control system (Optional:SYNTEC control system from Taiwan) |
| 18 | Computer Interface | USB interface |
| 20 | Collet | ISO30 |
| 21 | Inverter | 11kw Taiwan DELTA inverter |
| 22 | Software Compatibility | Type 3 /Artcam /Ucancam
|
