Green Machine Cnc vf 3 Concrete Wood Cutting Engraving Machine for Tree Roots Furniture

    Buy cheap Green Machine Cnc vf 3 Concrete Wood Cutting Engraving Machine for Tree Roots Furniture from wholesalers

    Buy cheap Green Machine Cnc vf 3 Concrete Wood Cutting Engraving Machine for Tree Roots Furniture from wholesalers
    • Buy cheap Green Machine Cnc vf 3 Concrete Wood Cutting Engraving Machine for Tree Roots Furniture from wholesalers

    Green Machine Cnc vf 3 Concrete Wood Cutting Engraving Machine for Tree Roots Furniture

    Ask Lasest Price
    Brand Name : Blue Elephant
    Model Number : ELE1325
    Certification : CE ISO9000 SGS BV TUV ISO9001
    Price : US $3800-6800 / Set
    Payment Terms : L/C, D/P, D/A, T/T, Western Union
    Supply Ability : 200 Set/Sets per Month
    Delivery Time : 15-30 working days after payment
    • Product Details
    • Company Profile

    Green Machine Cnc vf 3 Concrete Wood Cutting Engraving Machine for Tree Roots Furniture

    Green Machine Cnc vf 3 Concrete Wood Cutting Engraving Machine for Tree Roots Furniture

    Advantages of 1325 cnc engraving machine:

    • Classical table structure, strong and economical

    • DSP A18 control system, with one independent handle, very convenient to operate

    • One rotary device on one side of machine, suitable for making cylinder products.

    Features of wood cutting router:

    • Effective working area: 1300*2500*200mm
    • 3kw Changsheng water cooling spindle
    • 3.7kw Fuling inverter
    • DSP A18 control system
    • Rotary for 300mm diameter (4 jaws)
    • FL118motor and YAKO 2811 big system
    • 5.5kw Water circulation vacuum pump
    • 3kw Dust collector system with double bags
    • Helical rack
    • Taiwan TBI ball screw
    • Taiwan PMI square linear guide way for 20mm
    • Manual Tool sensor calibration
    • Manual oil lubrication system
    • Vacuum & T-slot working table
    • Japan Omron limit switch
    • Working voltage:380v 3phase 50HZ

    Product Details of wood cutting router:

    Parameters of wood cutting router::

    DescriptionParameter
    X,Y,Z Working Area1300x2500x200mm
    X,Y,Z Traveling Positioning Accuracy±0.03/300mm
    X,Y,Z Repositioning Accuracy±0.03mm
    Table SurfaceT-slot and vacuum working table
    X, Y Structure#20 Taiwan PMI linear guide, helical rack
    Z StructureTaiwan PMI Rail Linear guide and Ball Screw
    Spindle3kw Changsheng water cooling spindle
    Spindle Speed0-24000RPM
    Drive MotorsFL118 stepper motor and Yako 2811 big driver
    Working VoltageAC380V, 50Hz, 3PH (Option: 380V)
    Operating SystemDSP A18 4 axis control system
    Control boxSingle-sided independent control box
    Inverter3.7kw Fuling inverter
    Lubrication systemManual lubrication system
    Rotary deviceDiameters: 300mm ; Length: 2500mm
    X,Y Resolution<0.01mm
    Running Environment Temperature0 - 45 Centigrade
    Relative Humidity30% - 75%
    Pump5.5kw water circlulation vacuum pump( 380V, 3Ph, 50Hz)
    Dust collector3kw old type double pockets dust collector ( 380V, 3Ph, 50Hz)
    OptionalJapan Omron limit switch

    PS:All the working area and specifications can be customized according to your requests.


    Applications:

    • Making furnitur, doors, cabinets, legs of chairs etc.

    Samples:

    Packaging & Delivery:

    Packaging & Delivery
    Packaging Details: 1.Outside package:Standard marine export plywood case.
    2.inner package:Stretch film and plastic film for humidity.
    We can package according to your requests.
    Delivery Detail: Shipped in 15-18 working days after payment.


    Customers Feedback:


    Our Service:
    1, Within 7 days since your local customs clearance: if the cnc router’s any parts has any problems, we will change it free.
    2, Exceed 7 days since your local customs clearance but within warranty period: if the cnc router parts have any problems, we can change the old machine parts to new ones free, but you should pay all the shipping cost.
    3, Exceed warranty period: if the cnc router parts have any problems, we can offer new machine parts with cost price and you also should pay all the shipping cost.
    4, We offer 24 hours technical support by call, and email.
    5, Our technician can give you remote guide online(Skype or WhatsApp) if you have any question.
    6, We can record videos of operating the laser machine.
    7, Free training course in our factory.
    8.Machine will be adjusted before it is delivered, operation disk/CD was included.


    Welcome to our factory:

    • Jinan Blue Elephant CNC Machinery Co., Ltd is located in Jinan City, Shandong Province. We have always been developed to the research and manufacturer of CNC router machine and laser cutting engraving machine.
    • We have our R & D department, Quality control department, and after sale & service department.
    • Our products are widely used in Woodworking, Advertising, Model, Electric, CAD/CAM Industry model, Clothing, Package Printing, Marking, Laser sealing and so on.
    • We had got CE and ISO9001 certification always offer best quality machine.
    • Our Philosophy: To Be First Brand -- CNC Manufacturer & wholesaler Platform!

    • Just looking forward to service every customer, like you.

    Contact us:

    Skype: elephantcnc

    WhatsApp/Mobile: 0086-15064026772

    Web: www.elephant-cnc.com
