    Factory direct sales blue elephant dust cover cnc router , ele 1325 furniture machinery woodworking

    Ask Lasest Price
    Brand Name : Blue Elephant
    Model Number : ELE1325
    Price : 6000
    Payment Terms : L/C, D/A, T/T, Western Union
    Supply Ability : 200sets/month
    Delivery Time : 15days
    • Product Details
    • Company Profile

    Factory direct sales blue elephant dust cover cnc router , ele 1325 furniture machinery woodworking

    Factory direct sales blue elephant dust cover cnc router , ele 1325 furniture machinery woodworking

    Description of furniture machinery woodworking:

    • high efficiency: the vacuum adsorption table with the strong power vacuum pump , whole table absorption.
    • rapid running speed: two axes are rack gear, fast speed and high efficience, The highest speed is 45mpm.
    • fast carving speed: high-speed 1kw YASKAWA servo motor and drive, high precision helical rack drive, with the high power engraving spindle cutting faster.
    • Stable operation: adopting imported linear guide rail, Large bearing capacity , smooth running, high precision, long life, carving precisely.
    • Intelligent control:adopting DSP control system.It is very easy to master.
    • Sturdy and durable: Thicker and bigger welded Steel Square Tube Structure, Gantry moving, strengthen table makes positioning accuracy more accurate.

    Parameters of furniture machinery woodworking:

    DescriptionParameter
    modelELE-1325
    Working area(X*Y*Z)1300*2500*200mm
    Max rapid moving speed33000mm/min
    Max carving speed25000mm/min
    Cutting accuracy±0.01/300mm
    Repositioning Accuracy±0.01mm
    Table SurfaceVacuum Table
    FrameWelded Steel Square Tube Structure
    X, Y StructureRack and Pinion Drive, Hiwin Rail Linear Bearings
    Z StructureHiwin Rail Linear Bearings and Ball Screw
    Spindle Power6 kw HSD air cooling spindle
    Spindle Speed18000 rpm
    InveterImported DELTA
    Drive Motors1kw YASKAWA servo system
    Working VoltageAC380V/50/60Hz,3PH (Option: 220V)
    Command LanguageG Code
    Operating SystemDSP A11 control System
    ColletER32
    Software CompatibilityType3/UcancameV9 Software

    PS:All the working area and specifications can be customized according to your requests.

    Product details of furniture machinery woodworking:

    Welcome to our factory:


    • Jinan Blue Elephant CNC Machinery Co., Ltd is located in Jinan City, Shandong Province. We have always been developed to the research and manufacturer of CNC router machine and laser cutting engraving machine.
    • Our Philosophy: To Be First Brand -- CNC Manufacturer & wholesaler Platform!
    • Just looking forward to service every customer, like you.

    Contact us:

    Skype: elephantcnc

    WhatsApp/Mobile: 0086-15064026772

    Web: www.elephant-cnc.com
