    2050 Fabric Laser Cutting Machine Automatic Carousel Tool Changer For Corrugated Board

    Ask Lasest Price
    Brand Name : BLUE ELEPHANT
    Model Number : ELE2050
    Certification : CE, SGS, TUV, BV, ISO9000,ISO9001
    Price : US $25,000 - 38,000 / Set
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 200 Set/Sets per Month
    Delivery Time : 10-20 working days
    • Product Details
    • Company Profile

    2050 Fabric Laser Cutting Machine Automatic Carousel Tool Changer For Corrugated Board

    2050 Automatic Carousel Tool Changer Cnc Oscillating Knife Cutter Fabric Cutting Router Machine for Corrugated Board


    Advantages of oscillating knife cutter router:

    • Imported high-precision ball screw has smooth movement for Z axis, which can ensure high precision of machine tools.
    • We adopt well-known 14KW Italy HSD spindle in our Cnc router,which is famous brand and has many after service department all over the world. It is water cooling spindle, lower noise.
    • With high-performance Japan YASKAWA servo motor, the machine can work in high precision.The servo motor runs smoothly,no vibration phenomenon even in the low speed.And it has a strong ability of overload.
    • Designer perfectly selects the best machine accessories, minimizing the failure rate.
    • Breakpoint memory, continuing carving after power outage, forecasting processing time and other functions.
    • Advanced Taiwan Syntech system, easy operated with the handle.
    • Cnc router machines’ body is strong, rigid and durable.
    • Advantages of Oscillating knife cutting machine cnc leather cardboard cutter router machine with good price.

    Features of oscillating knife cutter router:

    • Effective working area 2000*5000 mm
    • Z axis 400 mm
    • 8 Carousel tool storage
    • 14kw Italy HSD ATC water cooling spindle,32000 rpm,ISO30
    • 15kw Taiwan Delta inverter
    • Japan 850W YASKAWA servo motors and 1kw drivers
    • Japan Shimpo Reducer
    • Taiwan Syntec control system 6MB
    • Tangential knife and an oscillating knife
    • HIWIN #25 linear square guide way for X,Y,Z axis
    • Taiwan TBI ball screw for Z axis
    • Vacuum table, 9 zones
    • Automatic Oil Lubrication System
    • Automatic Oil mist cooling sprayer
    • Vacuum table
    • Dust cover for Y axis
    • 2*7.5KWTongyouRotary vane Vacuum pumps ,oil free working ,air-cooled
    • 1.5KW new type dust collector

    Parameters of oscillating knife cutter router:

    DescriptionsParameters
    ModleELE2050ATC-O
    Working area2000*5000*400mm (can be customized)
    Working Voltage380V, 3PHASE, 50HZ (can be customized)
    Control SystemTaiwan SYNTEC 6MB control system
    Control box1.8m high control box
    Oscillating knifeGermany ECOCAM EOT-3
    Spindle14kw Italy HSD water cooling spindle
    Spindle speed0-12000RPM/MIN
    Tool magazineCarousel type + 8pcs ISO30 tool holders (Linear type for optional)
    Motor and Driver850w Japan YASKAWA servo motors and drivers
    Inverter15kw Taiwan DELTA inverter VFD-B
    StructureNew type thicker and bigger heavy duty welded frame and gantry
    Table surfaceT-slot and Vacuum Working Table with 9 Zones
    Gantry structureGantry Moving
    Lubrication systemAutomatic lubrication system
    CalibrationAutomatic tool sensor calibration
    Mist cooling sprayerAutomaitc oil mist cooling sprayer
    Transmission

    X,Y Axis: Helical rack, Taiwan Hiwin/PMI/ABBA 25# Rail Linear Bearing with dust hood protection for Y axis.

    Z Axis: Taiwan Hiwin/PMI/ABBA Rail 25# Linear Bearing & Taiwan TBI Ball Screw

    Vacuum pump2 sets 7.5kw Tongyou Pump (380V, 3PHASE, 50HZ)
    Dust Collector1.5kw new type double pockets dust collector (380V, 3PHASE, 50HZ)
    Command languageG Code
    ColorAccording to your reference
    ApplicationsLeather, Carpet, Carton, Wood, MDF, PVC, Acrylic, Carboard, Rubber, Corrugated box, Foam, Leather strip.

    PS:All the working area and specifications can be customized according to your requests.


    Product details of oscillating knife cutter router:


    Just looking forward to service every customer, like you.
